RG-MHMOD 24
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value) Factory Default
115 (73) 64 MONITOR 00 - OFF
01 - ON 01 - ON
116 (74) 65 PROGRAM 00 - Maintain
01 - Reset 60
02 - Reset 50 01 - Reset 60
117 (75) 66 HISTORY 00 - Maintain
01 - Clear 00 - Maintain
121 (79) 70 PID MODE 00 - Off
01 - Normal
02 - Reverse 00 - Off
125 (7D) 74 PID FB 00 - TB-5A
01 - TB-5B 00 - TB-5A
126 (7E) 75 FB @ MIN 0 - 65000 0 (0.0%)
127 (7F) 76 FB @ MAX 0 - 65000 65000 (100%)
128 (80) 77 P GAIN 0 - 9999 (0.0 - 999.9%) 50 (5.0%)
129 (81) 78 I GAIN 0 - 100 (0.0 - 10.0 sec) 0 (0.0 sec)
130 (82) 79 D GAIN 0 - 100 (0.0 - 10.0 sec) 0 (0.0 sec)
131 (83) 80 PID ACC 0 - 1000 (0.0 - 100.0 sec) 300 (30.0 sec)
132 (84) 81 MIN ALRM FB @ MIN - FB @ MAX 0.0%
133 (85) 82 MAX ALRM FB @ MIN - FB @ MAX 0.0%
149 (95) 98 LANGUAGE English
150 (96) 99 FAULT HISTORY (View Only) (N/A)
1 = Drive's programming parameter number; 2 = Two decimal places assumed (hundredths)
