Lenze E84AVTCExxxx TopLine C - Manual (Page 10)

X100 (400 V) 2 3.0 22 kW
l
10 EDK84VTCE223 DE/EN/FR/ES/IT 2.3
2
X100 (400 V) 3.0 22 kW
X100 − TN, TT
;
;
;
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1 … F3
K
Z
PE L3 L1 +UG -UG L2
X100
8400GG054 8400GG007
X100 − IT
;
;
;
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1 … F3
K
PE L3 L1 +UG -UG L2
X100
8400GG055 8400GG008
F L1, L2, L3 PE
EN 60204 UL
[A] [A] [A] [A] [mm 2 ]
[AWG]
[mm] [Nm]
[lb−in]
[mm 2 ]
[AWG]
[mm] [Nm]
[lb−in]
E84AVTCE3024xx0 10 C10 16 C16 15 15
1 ... 6
18 ... 10
14
0.5
4.4 2.5 ... 16
12 ... 6
14
3.4
30
E84AVTCE4024 16 C16 16 C16 20 20
E84AVTCE5524 20 C20 25 C25 20 20
E84AVTCE7524 20 C20 32 C32 20 25
1 ... 16
18 ... 6
14
1.2
10.6
2.5 ... 16
12 ... 6
14
3.4
30
E84AVTCE1134 32 C32 32 C32 30 40
E84AVTCE1534 32 C32 − − 40 −
E84AVTCE1834 50 C50 80 C80 40 60 1.5 ... 25
16 ... 2
14
3.5
31
2.5 ... 25
12 ... 2
16
4.0
35 E84AVTCE2234 63 C63 − − 50 −
