Technical data
General data and operating conditions
4
l
46 EDKRBS470R DE/EN/FR 8.0
Mounting conditions
Mounting location l The mounting location must comply with the
device features mentioned in the chapter "General
data".
l Flammable materials or substances may not be
placed in the vicinity of the brake resistor.
l The heat generated by the brake resistor must be
dissipated freely.
Mounting position
Standard Vertically suspended with connections at the bottom.
Variant Horizontally standing with fixing bracket at the
bottom. The permanent power P
d
is to be reduced by
20 %!
Free spaces
Standard at the top > 200 mm, to the sides > 25 mm, at the
bottom > 100 mm
Variant at the top > 200 mm, to the sides > 45 mm
