Key for overview
Position
Description
0
Controller
1
Fixing rails for standard mounting
2
Cover for the motor connection
3
Shield connection support with fixing screws (2 items)
1 support for the shield sheet for the supply connections
1 support for the shield sheet for the motor cable
4
EMC shield sheet with fixing screws (2 items)
1 shield sheet for the supply connections
1 shield sheet for the motor cable and the feed cable for the motor temperature monitoring with PTC ther-
mistor or thermal contact (NC contact)
5
EMC shield sheet with fixing screws for shielded control cables
6
Cover for the supply connections
Connections and interfaces
Position
Description
L1, L2, L3, PE Mains connection
+UG, −UG
DC supply
U, V, W, PE
Motor connection
T1, T2
Connection of PTC thermistor or thermal contact (NC contact) of the motor
X1
AIF interface (automation interface)
Slot for communication module (e. g. XT EMZ9371BC keypad)
X3
Jumper for setting analog input signal at X6/1, X6/2
X4
System bus (CAN) connection
X5
Connection of digital inputs and outputs
X6
Connection of analog inputs and outputs
X8
Connection of incremental encoder with TTL level or SinCos encoder and KTY temperature sensor of the motor
X9
Connection of digital frequency input signal
X10
Connection of digital frequency output signal
X11
Connection of K
SR
relay output for "safe standstill" (for variants V004 and V024 only)
Status displays
Position
LED red
LED green
Operating status
Off
On
Controller is enabled
On
On
Mains is switched on and automatic start is inhibited
Off
Blinking slowly
Controller is inhibited
Off
On
Motor data identification is active
Blinking quickly
Off
Undervoltage or overvoltage
Blinking slowly
Off
Active fault
