Function library LenzePLCToolBox.lib
Functions/function blocks
2.4 L_TBConvBitsToWord
2−4
L
LenzePLCToolBox.lib EN 1.5
2.4 L_TBConvBitsToWord
WORD L_TBConvBitsToWord (bBit0, bBit1, bBit2, bBit3,
bBit4, bBit5, bBit6, bBit7,
bBit8, bBit9, bBit10, bBit11,
bBit12, bBit13, bBit14, bBit15)
This function converts 16 single bit values into a value of type "word".
L_TBConvBitsToWord
bBit0
bBit1
bBit2
bBit15
Word (16 bits)
Transfer parameters
Identifiers Data type Info/possible settings
bBit0 Bool Bit 0 (valency: 2 0 )
bBit1 Bool Bit 1 (valency: 2 1 )
bBit2 Bool Bit 2 (valency: 2 2 )
... ... ...
bBit15 Bool Bit 15 (valency: 2 15 )
Return value: Word
Value Meaning
0 ... 65535 Value of type word" corresponding to the transmitted bit values.
Example
Calling the function in ST:
wResult := L_TBConvBitsToWord(0, 1, 1, 0, 1, 0, 0, 1,
1, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0);
(* dwResult = 406 *)
