Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Changing and saving parameters
l
24
EDKVS93−03 EN 3.0
Step
Key
sequence
Action
1.
Select the menu
z y Z Y
Use the arrow keys to select the desired menu
2.
Change to the code level
Z
Display of the first code in the menu
3.
Select code or subcode
y z
Display of the current parameter value
4.
Change to the parameter level
V
5.
When SHPRG is displayed, inhibit the
controller
S
1)
The drive coasts
6.
Change parameter
A
Z Y
Move cursor below the digit to be changed
B
y z
Change of digit
T y
T z
Quick change of digit
7.
Accept the changed parameter
Display of SHPRG or SHPRG
p T V
Confirm change to accept the parameter
Display "OK"
Display
p −
The parameter has been accepted immediately
8.
Enable the controller, if required
U
1)
The drive runs again
9.
Change to the code level
A
V
Display of the operating level
B
V
Display of the code with changed parameter
10. Change further parameters
Restart the "loop" with step 1. or 3.
11. Save changed parameters
A
z y Z Y
Select the code C0003 "PAR SAVE" in the menu
"Load/Store"
B
V
Change to the parameter level
Display "0" and "READY"
Select the parameter set in which
the parameters are to be saved
permanently
C
z
Save as parameter set 1:
ð Set "1" "Save PS1"
Save as parameter set 2:
ð Set "2" "Save PS2"
Save as parameter set 3:
ð Set "3" "Save PS3"
Save as parameter set 4:
ð Set "4" "Save PS4"
D
T V
When "OK" is displayed, the settings are permanently
saved in the selected parameter set.
12. Change to the code level
A
V
Display of the operating level
B
V
Display of C0003 "PAR SAVE"
13. Set parameters for another parameter
set
Restart the "loop" with step 1. or 3.
1)
The function of the
S key can be programmed:
C0469 = 1: Controller inhibit
C0469 = 2: Quick stop (Lenze setting)
