Installation
EDKRBM220W
2.0
l
- 2 -
Mechanical Installation
Ÿ Install resistors vertically with the feeder cable at the bottom
Ÿ Ensure a free space around the module resistor (see sketch; all dimensions in [mm])
Electrical Installation
Ÿ Connect brake resistor to the terminals of the motec BR1 and BR2. For this, remove the bridge from
BR1 to BR0.
Ÿ Interconnect cable 3 and 4 (temperature surveillance) into the locking of the corresponding mains
contactor of the supply.
Ÿ Maximum capacity of the temperature switch (normally-closed contact):
250 VAC / 0.5 A
Ÿ For possible connections see documentation of the motec.
Ÿ Connecting cable
- Length 2 m
- 5 x 1.5 mm
2 (AWG 15)
Ÿ Terminal assignment
- 1, 2 = Resistor
- 3, 4 = Temperature switch
- ye/gr = PE
