5 Electrical installation
Wiring
EDK82ZAFBC−001 DE/EN/FR 7.2
40
l
H1_E_INST−INS_Klemmenbeleg
X3/ Signal type Function Level
(Lenze setting: Bold print)
62 Analog
output Output frequency 0 +6 V
0 +10 V
1)
7 − GND1, reference potential for analog signals −
8 Analog
input Input for actual value or setpoint
Change range using the DIP switch and C0034
l Voltage signal 0 +5 V
0 +10 V
−10 V +10 V
2)
l Current signal 0 +20 mA
+4 +20 mA
+4 +20 mA (open−circuit
monitored)
9 − Internal, stabilised DC voltage supply for setpoint
potentiometer +5.2 V
20 − Internal DC voltage supply for control of digital
inputs and outputs +20 V ±10 % (ref.: X3/7)
28
Digital
inputs
Controller inhibit (CINH) 1 = enable
E1 3) Activation of JOG frequencies
JOG1 = 20 Hz
JOG2 = 30 Hz
JOG3 = 40 Hz E1 E2
JOG1 1 0
E2 3) JOG2 0 1
JOG3 1 1
E3 DC−injection brake (DCB) 1 = DCB
E4 Change of direction of rotation
CW/CCW rotation E4
CW 0
CCW 1
39 − GND2, reference potential for digital signals −
A1
Digital
output
Ready for operation with
– internal supply:
– external supply: 0 +20 V
0 +24 V
59 − DC supply for X3/A1
– internal (jumper to X3/20):
– external: +20 V
+24 V
1) Output level 0 +10 V: Adapt offset (C0109/C0422) and gain (C0108/C0420)
2) Adjust offset (C0026) and gain (C0027) separately for each function module:
After replacing the function module or the standard device
After loading the Lenze setting
3) Alternatively frequency input 0 10 kHz single−tracked or 0 ... 1 kHz double−tracked, configuration
via C0425
