6 Operation
Description of the display elements
EDK82ZBC DE/EN/FR 3.1
50
H1_Bedienung-M5user2all
Explanation
Meaning
Display
Function bar 1
Setpoint selection via
Not possible if password protection is active
(display =
”loC”
)
Display function:
z
Display user menu, memory
location 1 (C0517/1)
z
Display active parameter set
Active after every mains connection
Select codes
Four-digit display of the active code
Select subcodes
Three-digit display of the active subcode
Change parameter value of a
code/subcode
Five-digit display of the actual value
Display values which have more than
5 digits
H:
higher-order digits
Display of
”HI”
L:
lower-order digits
Display of
”lo”
Function bar 2
Select parameter set 1 ... 4 for
changing
z
Display of e.g. PS
2
(
)
z
The parameter sets can only be activated
via digital signals (configuration with
C0410)
Select node of the system bus (CAN)
The selected node can be parameterised from
the current drive
= Function is active
Select menu
The user menu is active after every
mains switching
user
List of the codes in the user menu
(C0517)
all
List of all codes
funCi
Only specific codes for bus function
modules, e.g. INTERBUS,
PROFIBUS-DP, LECOM-B, ...
