Technical data
Protective insulation
6
EDK82ZAFFC−010 DE/EN/FR 5.0
37
l
H1_Daten−bemessDat
Ambient conditions
Climatic conditions
Storage 1 K3 acc. to IEC/EN 60721−3−1 − 25 ... + 60 °C
Transport 2 K3 acc. to IEC/EN 60721−3−2 − 25 ... + 70 °C
Operation 3 K3 acc. to IEC/EN 60721−3−3 − 20 ... + 60 °C
Degree of pollution 2 acc. to IEC/EN 61800−5−1
Enclosure IP20
X3.2/ Level
DI2 Input resistance: 3.3 k
W
0 = LOW (0 V DC − 0% ... +3 V DC + 0%)
1 = HIGH (+12 V DC − 0% ... +30 V DC + 0%)
Reference: GND
DI3
X3.3/ Level
28 Input resistance: 3.3 k
W
Controller inhibit
l Start = HIGH (+12 V DC − 0% ... +30 V DC + 0%)
l Stop = LOW (0 V DC − 0% ... +3 V DC + 0%)
20 Max. load: 70 mA
Reference: GND ASi
Protective insulation
Insulation voltage between bus and ... Type of insulation (to EN 61800−5−1)
l 8200 vector/motec power stage Double insulation
l Reference earth/PE Functional insulation
l Terminal X3.2/DI2 or X3.2/DI3 Functional insulation
l Terminal X3.3/20 No insulation
l Terminal X3.3/28 Functional insulation
