Preface and general information
EDKMF2176X DE/EN/FR 4.2
11

H1vorwrt-2176_Funktion
4 Preface and general information

Please read these instructions and the documentation of the standard device
before you start working!
Observe the safety instructions given therein!
CAN2
CAN1
2176
24 V
GND
LO
HI 3
GND
4
5
1
2
T ype
Id.-No. Pr
od.-No.
Ser
.-No.
Hans-Lenze-Straße 1 D31855 Aerzen Made in Germany
EMF2176IB
L
0
2
4
3
5
1
6
2176_001
Connections
Pos. Description
 DC-24-V supply voltage
 Segment CAN2
 Segment CAN1
Displays
Pos. Colour Status Description
 Red On Fault in segment CAN 2
 Green On Transmission of segment CAN 2
 Red On Fault in segment CAN 1
 Green On Transmission of segment CAN 1
