Commissioning – Lenze E82ZAFCC100 User Manual
Page 59
Commissioning
Possible settings via DIP switch
7
EDK82ZAFCC-100 DE/EN/FR 5.0
59
H1inbet-Baudrate
Baud rate setting
ƒ The baud rate must be the same for all CAN nodes.
ƒ The following baud rates can be set:
Baud rate [kbps]
Switch
7
8
9
20
ON
OFF
ON
50
OFF
ON
ON
125
OFF
ON
OFF
250
OFF
OFF
ON
500
OFF
OFF
OFF
1000
ON
OFF
OFF
Note!
Switch off the voltage supply of the function module/standard device and
then switch it on again to activate the changed settings.
