3 installazione meccanica, Installazione meccanica, 3installazione meccanica – Lenze E94AZHN0025 User Manual
Page 98
3
Installazione meccanica
EDK94AZHN25 DE/EN/FR/ES/IT 2.2
98
l
H1_MechINS−MechInstall_Schr
3
Installazione meccanica
Procedura di montaggio
Montaggio su guida DIN
1. Montare il comando freno motore con l’adattatore per guida DIN
2 sulla guida
inferiore.
2. Bloccare fino all’arresto il comando freno motore sul bordo superiore della guida
vincendo la forza elastica.
3. Verificare che il modulo di comando del freno motore sia correttamente montato.
