Installation
Mounting steps
MP 2xxx DVI / MP 5xxx DVI / MP 9xxx DVI
4
l
34 MA_ELx0xx DE/EN/FR/ES/IT 2.0
)
Note!
Types MP 5020 DVI, MP 5050 DVI, and MP 5070 DVI can be installed
in any control panel and in 19" mounting racks in accordance with
DIN 41494.
19" mounting rack installation (only MP 5020 DVI, MP 5050 DVI, and MP
5070 DVI)
How to perform the installation:
1. Remove the set screws from the back of the front frame.
2. Drill through the blind holes at the back of the front frame using a 6.5
mm drill.
3. Place the device in the 19" mounting rack and screw it.
