Installation électrique, Installation – Lenze MP 9000 DVI Mounting Instructions User Manual
Page 52
Installation
Installation électrique
l
52
MA_ELx0xx DE/EN/FR/ES/IT 2.0
4.5
Installation électrique
L1
N
PE
L1 N
+
0V
+24
+
~
=
0 VPE +24 V
+
0
1
F
S
MP9000DVI−006
0
Monitor Panel (écran de supervision)
1
Bloc d’alimentation
)
Remarque importante !
Respecter la tension d’entrée maximale admissible.
Protéger l’appareil de manière adaptée côté entrée contre les
fluctuations de tension et les pointes de tension.
