Ins_PY_89_En_102513
5
Item: PY 89
Read all instructions BEFORE assembly and USE of product.
( 3) Pull upward until they lock securely into place
(4) Lift long side rails until they lock into place. If any of the rails does
not lock easily, lift the centre locking hub higher
( 5) Press the centre locking hub down all the way and check that it is
securely in place.
( 6) Insert the mattress
( 7) Secure mattress by sliding the two straps on
the mattress ends (A) through the slots at
either end of the Play Yard base (B)) and
fasten.
1) Release hook & loop mattress straps and remove the mattress.
2) Hold center hub strap and lift up. Locate side hinge locks
identified by a printed arrow head (B). Starting with the longer sides,
press button at underside of the locking hinge (A) and release
( 3) Repeat point 2 this time with the shorter sides.
(4) When all 4 hinges have been released, pull up the center
locking hub.
( 5) Wrap mattress around the Play Yard and secure with hook & loop straps.
( 6) Insert carry bag cover over the Play Yard. Close the zipper,
Assembling Your Crib Yard Folding Your Crib Yard
(1) Unzip nylon case, remove Play Yard and stand unit upright
Unfasten hook & loop straps and remove mattress pad.
(2) Grasp both short sides of the Play Yard
