VHD F
lybar
Weights & Stregths
Weights & Strengths
8
The ES Flybar System presents several configurations of system design product combinations for
suspension and rigging. Each component has to be factored into the total weight being suspended.
PART WEIGHT PER UNIT
CROSSMEMBER - Hanging Bracket (part of KVV 987 309) 5,5 kg (12.13lbs)
PICKPOINT - Hanging Arm with Fixation Chain 6 kg (13.23lbs)
VHD2.0 TOP ARM (pair), (KVV 987 309) 6,5 kg (14.33lbs)
VHD2.0 TOP EXTENSION ARM (pair), (KVV 987 306) 7,5 kg (16.53lbs)
VHD BASS ARM (pair), (KVV 987 307) 8,5 kg (18.74lbs)
VHD BASS EXTENSION ARM (pair), (KVV 987 308) 9,5 kg (20.95lbs)
VHD1.0 DOWNFILL ARM (pair), (KVV 987 310) 3 kg (6.62lbs)
TOTAL WEIGHT OF ONE COMPLETE SYSTEM WITH TWO TOP ARMS 18 kg (39.69lbs)
TOTAL WEIGHT OF ONE COMPLETE SYSTEM WITH FOUR TOP ARMS 25,5 kg (56.22lbs)
TOTAL WEIGHT OF ONE COMPLETE SYSTEM WITH TWO TOP ARMS 27,5Kg (60.63lbs)
AND TWO SUBWOOFER ARMS
MAXIMUM SWL OF ONE COMPLETE SYSTEM 400kg (881.84lbs)
FOR CERTIFICATION OF FLYBAR COMPONENTS AND PINS PLEASE VISIT www.kv2audio.com
