Kuryakyn 4128 TECH-CONNECT POUCH W/ACCESSORY BAR MOUNT - Manual (Page 3)

PAGE
3
STEP 7
To remove the Tech-Connect Pouch from the bike for storage, loosen the nylon lock nut on the
back side of the holder until it clears the threads. PIC 7 Snap the
Tech-Connect Pouch off of the ball. PIC 8 Remove the nylon lock nut and
thread it to the Tech-Connect Pouch for storage.
STEP 8
To replace the Tech-Connect on the swivel ball, remove the nylon lock
nut from the back. Slide the lock nut over the swivel ball, snap the
Tech-Connect back on the swivel ball and thread the lock nut onto
the Tech-Connect. Tighten the lock nut to the desired tension.
STEP 9
To adjust the angle of the Tech-Connect Pouch, loosen the nylon lock
nut, adjust the Tech-Connect Pouch to the desired position and tighten
the lock nut. PIC 5 The lock nut will allow you to keep the Tech-Connect
Pouch in the same position or, with a little less tightness, allow you to
move the Tech-Connect Pouch on the swivel ball.
Küryakyn is not responsible for items that may be stolen or
damaged in relation to the use of this product.
ENSURE THAT THERE IS CLEARANCE AT ALL POINTS
WHEN THE HANDLEBARS ARE TURNED.
INSUFFICIENT CLEARANCE MAY CAUSE DAMAGE TO
THE MOTORCYCLE OR CAN CAUSE LOSS OF
CONTROL THAT COULD RESULT IN SEVERE INJURY
OR DEATH.
Ensure that the Mobile Device is secure in the Tech-Connect
Pouch. Küryakyn is not responsible for any Device that is
damaged from use in this Pouch or from the Pouch not being
properly secured to the motorcycle.
The Tech-Connect Pouch is not waterproof. Remove the
Mobile Device and stow during inclement weather. Küryakyn
will not be responsible for any Mobile Device damaged when
using this pouch.
Motorcycling can be done in a harsh environment. Make sure
your Mobile Device is appropriate for this application.
DO NOT ATTEMPT TO OPERATE OR REMOVE THE
MOBILE DEVICE FROM THE POUCH WHILE
OPERATING THE MOTORCYCLE.
It is the installer’s responsibility to ensure that all of the fas-
teners (including preassembled) are tightened before
operation of the motorcycle. Küryakyn will not issue a
warranty on components lost due to improper installation.
Periodic maintenance may be required.
Ride On!
TECH-CONNECT POUCH
INSTALLATION
PIC 5
PIC 8
USE 1/4” FLAT WASHER
FIRST, THEN 1/4” LOCK
WASHER, THEN ACORN
NUT HERE
PIC 7
NYLON LOCK NUT
USE NYLON LOCK NUT TO ADJUST HOLDER
PIC 6
REMOVE
THIS AREA
AS DEEP AS
NEEDED TO
HOLD
DEVICE
FINGERS ON BACK PLATE
SNAP OVER BALL
