Operation 18
BOXLIGHT XD-15c User’s Guide
4. Control Menu
5. PIP Menu
These functions are valid only when the input mode is PC and the PIP source is Video or
S-Video.
Language
Language sets the OSD to display in one of 7 languages.
Use
3 / 4 key to select the languages: English, French, Ger-
man, Italian, Spanish, Simplified Chinese and Traditional Chi-
nese.
OSD
Selects a desired OSD position.
OSD Time
Sets the length of time the OSD will remain active after the last
time you pressed the button. The range is from 5 to 60 sec-
onds in 5-second increments.
Auto Off
Sets the length of time to shut off the system when no input is
detected.
Reset
Returns all settings to the time of manufacturing.
Lamp Hour
Shows lamp usage time.
PIP Source
Selects the source for the PIP.
PIP Size
Uses
3 / 4 key to scroll through the 4 alternatives: Off,
Small, Medium, Large.
PIP Position
Selects a desired position for the PIP.
H Position
Adjusts the horizontal position of the PIP image.
V Position
Adjusts the vertical position of the PIP image.
More Options
Uses
3 / 4 key to select more PIP functions including Bright-
ness, Contrast, Color, Tint, Sharpness and System.
Brightness
Adjusts the brightness of the PIP image.
Contrast
Adjusts the degree of difference between dark and light for the
PIP image.
Color
Increases or decreases the color range (R, G, B) of the image.
Tint
Adjusts the image to make it appear more red or blue.
Sharpness
Adjusts the image to make it appear sharper or softer
System
Selects PIP image systems: Auto, NTSC, PAL, SECAM
