9
3. Technical specifications
Recirculating Cooler
Cooling FL1201 FL1203
air cooled
air cooled
Working temperature range °C -20 ... +40 -20 ... +40
Temperature stability °C ±0.5
Temperature selection: digital
via key pad indication on LED-DISPLAY
remote control via personal computer indication on monitor
Temperature indication: LED-DISPLAY
Resolution °C 0.1
Temperature control PID 1
Temperature sensor Pt 100
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Cooling capacity
Medium: Mixture water-glycol °C
kW +20 0 -10 +20 0 -10
1.2 0.9 0.6 1.2 0.8 0.5
Cooling compressor 1-stage
Refrigerant R404A
Electrical connections:
Computer interface RS232
Alarm output for external alarm signal
Circulating pump:
discharge, max. at 0 bar l/min 23 40
pressure, max. at 0 liter bar 1.0
pressure, adjustable at 0 Liter bar ---- 0.5 ... 3.0
Feed pressure indication bar Manometer Manometer
Filling level indicator sight glass
Filling volume from ... to liters 12 ... 17
Dimensions (WxLxH) cm 50x76x64
Weight kg 76 91
Ambient temperature range °C 5 ... 40
Return flow temperature °C 80 max.
IP class according to IEC 60 529 IP 21
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50 207-253 / 50
Current input at 230 V A 7 12
Mains power connection 208 - 220 V/60 Hz V/ Hz 197 - 242 / 60 197 - 242 / 60
Current input at 208V / 220 V A 6 ----
Mains power connection 115 V/60 Hz V/ Hz 103 -127 / 60 ----
Current input at 115 V A 14 ----
All measurements have been carried out at: rated voltage and frequency,
ambient temperature: 20 °C
