JULABO FPW50-HE Refrigerated and Heating Circulators - Manual (Page 25)

HE
25
16a
16b Mains fuses for circulator, T16A
Mains fuses for cooling machine, T10A
17a
17b Mains power cable with plug for circulator
Mains power cable with plug cooling machine
18 Built-in mains outlet for connection of circulator
19
Drain screw with drain connection
20 Venting grid, removable
21
22
Pump connectors suction pump pressure pump
23 Selector dial for cooling machine (only F25, F34)
Position "1" for operation with HE circulator.
24
Cooling water OUTLET and INLET.
¾"
