JULABO F38-EH Refrigerated and Heating Circulators - Manual (Page 9)

EH
9
2.4. Technical specifications
F38-EH
Working temperature range °C -35 ... 80
Temperature stability °C ±0.03
Temperature selection digital
Temperature indication LED
Resolution °C 0.1
ATC - Absolute Temperature Calibration 1-point
Temperature control PID1
Heater wattage (at 230 V) kW 2.0
Cooling capacity °C
Medium ethanol kW
+20 0 -20
0.92 0.66 0.32
Refrigerant R404A
Circulating pump:
discharge, max.at 0 bar l/min 15
pressure, max. at 0 l bar 0.35
Electrical connections:
External alarm device Vdc/mA 24-0 / max. 25
Overall dimensions (WxDxH) cm 44x64x86
Bath opening (WxL) cm 35x41
Bath depth cm 27
Filling volume from ... to liters 38 ... 45
Weight kg 72
Ambient temperature °C 5 ... 40
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current input (at 230 V) A 13
Mains power connection 230 V/60 Hz V/ Hz 207-253 / 60
Current input (at 230 V) A 13
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C
Technical changes without prior notification reserved.
