5.3. Tubing
Recommended tubing:
JULABO
Order No.
Suitable
for
8930008 1m
CR
®
tubing, 8mm inner dia.
AWC100
8930010 1m
CR
®
tubing, 10 mm inner dia.
AWC100
Connect the tubings for cooling the external system to the pump
connectors for feed and return (5 and 6) on the front of the recirculating
cooler and secure the screw connection firmly.
Caution:
Fasten tubing to prevent slipping.
After starting operation, please check all tubing connections in the
cooling water circuit for leaks.
5.4. Filling
Remove the lid (3) and fill in water until the unit is filled to the maximum.
If the water level sinks below the minimum, take care to fill in more liquid.
Notice:
Take care the filling level does not exceed the maximum.
When switching the unit off, take care that water does not flow back to
the storage tank. To prevent this use a shut-off valve or a tube clamp for
the external circuit.
5.5. Draining
Caution:
Switch off the unit and disconnect mains power cable.
Remove the lid (3).
Use a suitable vessel.
Hold the unit on the handle (4) and at the bottom of the front and tilt it to
the front.
