11
PLAN - 201B COMPLETE BLACK TRACK
201 BLACK SINGLE CARRIER AND
202 BLACK MASTER CARRIER
203 BLACK DOUBLE END PULLEY 204 BLACK SINGLE END PULLEY
210B BLACK TRACK
TRACKS AT CENTER
OVERLAP
200 SERIES BLACK TRACK
20 BLACK PIVOT DEVICE
ELEVATION - 201B COMPLETE BLACK TRACK
&
5-3/4"
204 BLACK
SINGLE END PULLEY
201 BLACK
SINGLE CARRIER
206 BLAK CLAMP HANGER
202 BLACK MASTER CARRIER
209 BLACK END STOP
& CORD SUPPORT
205 BLACK
OVERLAP CLAMP
214 BLACK OPERATING LINE
208 BLACK ADJUSTABLE FLOOR BLOCK
203 BLACK DOUBLE END PULLEY
2'-0" OVERLAP
2"
1-3/4"
4-1/8"
2-1/16"
RUBBER
BUMPER
3/8"Ш
4-1/4"
1-1/2"
7-1/4"
10-3/8"
2-1/8"
4-1/4"
7-1/4"
3-1/8"
4" 4"
3-1/8"
7-1/4"
2-7/8"
3-5/8"
