STANDARD-DUTY STRAIGHT TRACK
Provide Model 101S as manufactured by H & H Specialties Inc., South El Monte, CA.
Track shall be 16 gauge galvanized steel, roll-formed to 1-3/4" wide X 2" high with continuous slot in bottom. Provide unspliced
in lengths up to 26'.
Suspend track with two-piece clamp hanger formed from 11 gauge steel. Provide 2' overlap at center, rigidly separated by two
overlap clamps. Install end stop with cord support at each overlapping track end. Where lengths exceed 26', connect tracks with
12" long, two-piece splicing clamp of 12 gauge steel.
Provide single carriers, spaced on 12" centers, constructed of two polyethylene wheels fastened parallel to formed steel carrier
body with swivel hook for attachment of curtain.
Master carriers shall be 4-wheel assemblies with formed steel bodies and two swivel hooks each. Connect to operating line with
two machined steel cord clamps captured within each body.
Single and double end pulleys shall clamp securely to the underside of the track channel and shall contain 2-1/2" diameter sheaves
enclosed in steel housings to prevent operating line from escaping the grooves. Nylatron GS sheaves shall be molded around
shielded and greased ball bearings and grooved to accommodate up to 1/4" operating line.
Provide floor block in 12 gauge steel housing containing 4" Nylatron GS shielded ball bearing sheave. Sheave axle shall lock at
any point within 9" vertical slots to allow tension adjustment of operating line.
Black operating line shall be 1/4" diameter, stretch-resistant rope with spun polyester outer jacket braided over solid aramid
core.
All steel components shall be zinc plated to resist corrosion.
GENERAL SPECIFICATIONS:
100 SERIES COMPLETE TRACK COMPONENT GUIDE
For COMPLETE tracks supplied with aluminum, substitute 110A for 110S.
PART No. DESCRIPTION 101S 101W 116S 116W
101 Single Carrier ŏ ŏ
102 Master Carrier ŏ ŏ
103 Double End Pulley ŏ ŏ
104 Single End Pulley ŏ ŏ
105 Overlap Clamp ŏ ŏ
106 Clamp Hanger ŏ ŏ ŏ ŏ
107* Splice ŏ ŏ ŏ ŏ
108 Black Adjustable Floor Block ŏ ŏ
109 End Stop & Cord Support ŏ ŏ ŏ ŏ
110S* Track ŏ ŏ ŏ ŏ
114 1/4” Operating Line ŏ ŏ
116 Nylon B.B. Single Carrier ŏ ŏ
117 Nylon B.B. Master Carrier ŏ ŏ
*
Track lengths and splices supplied as required from stock sizes.
100 SERIES BLACK COMPLETE TRACK COMPONENT GUIDE
Note: Aluminum track is not offered in black.
PART No. DESCRIPTION 101SB 101WB 116SB 116WB
101B Black Single Carrier ŏ ŏ
102B Black Master Carrier ŏ ŏ
103B Black Double End Pulley ŏ ŏ
104B Black Single End Pulley ŏ ŏ
105B Black Overlap Clamp ŏ ŏ
106B Black Clamp Hanger ŏ ŏ ŏ ŏ
107B* Black Splice ŏ ŏ ŏ ŏ
108 Black Adjustable Floor Block ŏ ŏ
109B Black End Stop & Cord Support ŏ ŏ ŏ ŏ
110S-B* Black Track ŏ ŏ ŏ ŏ
114 1/4” Operating Line ŏ ŏ
116B Black Nylon B.B. Single Carrier ŏ ŏ
117B Black Nylon B.B. Master Carrier ŏ ŏ
*
Track lengths and splices supplied as required from stock sizes.
&
