Grayhill Racks 4 Channel User Manual

Racks 4 channel, 4 channel rack: g5, 4 channel rack: standard

Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com

System 50

9 8 7 6 5 4 3 2 1

OUTPUT

INPUT

STANDOFF I.D. 0.15 ( 3,8),DIA.
(4 PLACES)
CLEARANCE FOR #6 SCREW

9 POSITION TERMINAL
STRIP FOR GROUND
AND LOGIC SIGNALS

3.00

(76,2)

3.50

(88,9)

0.25 (6,4)

4.00 (101,6)

4.50 (114,3)

STATUS LED

3.3K RESISTOR

5 AMP FUSE

TERMINAL STRIP FOR
FIELD WIRING

2.20 (55,9)

MAX.

0.75 (19,1)

MODULE SHOWN FOR
REFERENCE ONLY

NOTE: MAXIMUM
TERMINAL SCREW
TORQUE NOT TO
EXCEED 5 IN-LBS.

4 CHANNEL RACK: G5

Part No. 70RCK4
Dimensions are shown in inches
(and millimeters).
All tolerances are ± 0.010 (0,25)
unless otherwise specified.

4 CHANNEL RACK: Standard

Panel Mount

DIN-Rail

Mount

RACKS
4 Channel

FEATURES
• Use for Isolating and Coverting Signal Types to

Standard Logic Voltages

• Terminal Block Connection for Input and Output
• Available for Standard and G5 I/O Modules
• Panel and DIN Rail Mount Versions
• UL, CSA Certified

System 50

AC OUTPUT

DC OUTPUT

AC INTPUT

DC INTPUT

1 2 3 4 5 6 7 8 9

9 8

7 6 5 4 3

2 1

2.75 (69,85)

3.25 (82,55)

2.75

(69,85)

.76 (19,30)

4.27

(108,46)

.25

(6,35)

SWAGED
STANDOFF
THRU HOLE
.15 (3,81) DIA.
(4 PLACES)
(CLEARANCE
FOR #6 SCREW)

9 POSITION
TERMINAL
STRIP FOR
CONTROL
LOGIC

3.36

5,34)

.75

(19,05)

9 POSITION
TERMINAL
STRIP FOR
FIELD WIRING

4.00

(101,6)

4.70

(119,38)

DIN-RAIL CARRIER

NOTE: MAXIMUM TERMINAL
SCREW TORQUE NOT TO
EXCEED 5 IN-LBS.

Part No. 70GRCK4
Dimensions are shown in inches
(and millimeters).
All tolerances are ± 0.010 (0,25)
unless otherwise specified.
