Grayhill Modules AC/DC Input User Manual
Page 2
I/O Modules
4#;*+..X 0%T IJE +..)418' 8'07' #4#0)'X ..+01+5 JNIFIgIMMK *10'U KNLgGIHgENHN #:U KNLgGIHgFLFN 999T)4#;*+..T%1/
Type/Function
Grayhill Part Number
G5, Non-Polarized, Status LED
70G-IDC5G
70G-IDC5NP
70G-IDC15NP
Specifications
Units
Maximum Input Voltage
Vac/Vdc
60
32
32
Input Voltage Range
1
Vac/Vdc
35-60
15-32/10-32
15-32/10-32
Input Current @ Max. Input Voltage
mA
6
18
18
Maximum Turn-on Time
mSec
10
5
5
Maximum Turn-off Time
mSec
10
5
5
Nominal Input Resistance (Rx)
W
10K
1.8K
1.8K
Maximum Pick Up Voltage (Output Low)
Vac/Vdc
35
15/10
15/10
Minimum Drop Out Voltage (Output High)
Vac/Vdc
9
3
3
Nominal Logic Voltage (Vcc)
Vdc
5
5
15
Logic Voltage Range: Std & Mini
Vdc
4.5-6
4.5-6
10-18
Max. Logic Supply Current
@
Nominal
Vcc
mA
10
10
10
Type/Function
Grayhill Part Number
Miniature, Non-Polarized
70M-IDC5G
70M-IDC5NP
70M-IDCI5NP
Standard, Non-Polarized
70-IDC5G
70-IDC5NP
70-IDC15NP
70-IDC24NP
Specifications Units
Maximum Input Voltage
Vac/Vdc
60
32
32
32
Input Voltage Range
1
Vac/Vdc
35-60
15-32/10-32
15-32/10-32
15-32/10-32
Input Current @ Max. Input Voltage
mA
6
18
18
18
Maximum Turn-on Time
mSec
10
5
5
5
Maximum Turn-off Time
mSec
10
5
5
5
Nominal Input Resistance (Rx)
W
10K
1.8K
1.8K
1.8K
Maximum Pick Up Voltage (Output Low)
Vac/Vdc
35
15/10
15/10
15/10
Minimum Drop Out Voltage (Output High)
Vac/Vdc
9
3
3
3
Nominal Logic Voltage (Vcc)
Vdc
5
5
15
24
Logic Voltage Range
Vdc
3-6
3-6
8-18
15-30
Max. Logic Supply Current
@
Nominal
Vcc
mA
10
10
10
10
Available from your local Grayhill Distributor. For
prices and discounts, contact a local Sales Office,
an authorized local Distributor or Grayhill.
f 02761&7.'5
SPECIFICATIONS: By Part Number
Standard and Miniature Modules
G5 Modules
Type/Function Grayhill Part Number
Dual, Non-Polarized, Status LED
70L-IDCNP
Specifications Units
Maximum Input Voltage
Vac/Vdc
32
Input Voltage Range
1
Vac/Vdc
15-32/10-32
Input Current @ Max. Input Voltage
mA
17
Maximum Turn-on Time
mSec
5
Maximum Turn-off Time
mSec
5
Nominal Input Resistance (Rx)
W
1.9K
Maximum Pick Up Voltage (Output Low)
Vac/Vdc
5/10
Minimum Drop Out Voltage (Output High)
Vac/Vdc
3
Nominal Logic Voltage (Vcc)
Vdc
5
Logic Voltage Range
Vdc
4.5-28
Max. Logic Supply Current
@ Nominal Vcc
mA
6/CH
Module ID Resistance to Logic Ground
W
0
1
For input voltages in the range of 90 to 140 Vdc, use AC input modules 70-IAC5, 70M-IAC5, 70G-IAC5
or 70L-IAC. For input voltages in the range of 180 to 280 Vdc, use AC input modules 70-IAC5A,
70M-IAC5A, 70G-IAC5A or 70L-IACA.
OpenLine
®
Modules
I/O
17
