SPECIFICATIONS: By Part Number
Standard and Miniature Modules
Type/Function
Grayhill Part Number
Miniature
70M-IAC5
70M-IAC5A
70M-IAC15
70M-IAC15A
70M-IAC24
70M-IAC24A
Standard
70-IAC5
70-IAC5A
70-IAC15A
70-IAC24
70-IAC24A
Specifications Units
Nominal Input Voltage
Vac
120
240
120
240
120
240
Input Voltage Range
1
Vac/Vdc
90-140
180-280
90-140
180-280
90-140
180-280
Input Current @ Maximum Input Voltage
mA, rms
8
6
8
6
8
6
Nominal Input Resistance (Rx)
W
22K
60K
22K
60K
22K
60K
Maximum Pick-Up Voltage (Output Low)
Vac
90
180
90
180
90
180
Minimum Drop-Out Voltage (Output High)
Vac
25
50
25
50
25
50
Nominal Logic Voltage (Vcc)
Vdc
5
5
15
15
24
24
Logic Voltage Range
Vdc
3-6
3-6
8-18
8-18
15-30
15-30
Max. Logic Supply Current @ Nominal Vcc
mA
10
10
10
10
10
10
02761&7.'5
G5 Modules
Type/Function
Grayhill Part Number
G5, Status LED
70G-IAC5
70G-IAC5A
70G-IAC15
70G-IAC15A
70G-IAC24
70G-IAC24A
Specifications Units
Nominal Input Voltage
Vac
120
240
120
240
120
240
Input Voltage Range
1
Vac/Vdc
90-140
180-280
90-140
180-280
90-140
180-280
Input Current @ Maximum Input Voltage
mA, rms
8
6
8
6
8
6
Nominal Input Resistance (Rx)
W
22K
60K
22K
60K
22K
60K
Maximum Pick-Up Voltage (Output Low)
Vac
90
180
90
180
90
180
Minimum Drop-Out Voltage (Output High)
Vac
25
50
25
50
25
50
Nominal Logic Voltage (Vcc)
Vdc
5
5
15
15
24
24
Logic Voltage Range
Vdc
4.5-6
4.5-6
10-18
10-18
17-30
17-30
Max. Logic Supply Current @ Nominal Vcc
mA
10
10
10
10
10
10
OpenLine
®
Modules
Grayhill Part Number
70L-IAC
70L-IACA
Nominal Input Voltage
Vac
120
240
Input Voltage Range
1
Vac/Vdc
0-140
0-280
Input Current @ Max. Input Voltage
mA, rms
8
6
Nominal Input Resistance (Rx)
W
22K
64K
Max. Pick-Up Voltage (Output Low)
Vac
90
180
Min. Drop-Out Voltage (Output High)
Vac
25
50
Nominal Logic Voltage (Vcc)
Vdc
5
5
Logic Voltage Range
Vdc
4.5-28
4.5-28
Max. Logic Supply Current @ Nominal Vcc
mA
6/CH
6/CH
Module ID Resistance to Logic Ground
W
0
0
1
For input voltages in the range of 15-32 Vac, or 35-60 Vac, see DC input Modules with the NP
or G suffix.
Available from your local Grayhill Distributor. For
prices and discounts, contact a local Sales Office,
an authorized local Distributor or Grayhill.
