762761&7.'5
Miniature, Normally Open, Random Turn-on 70M-OAC5A-11
Miniature, Normally Open, Zero Voltage Turn-on (ZVT) 70M-OAC5 70M-OAC5A 70M-OAC15 70M-OAC24 70M-OAC24A
Miniature, Normally Open, ZVT, Inductive Load 70M-OAC5-L 70M-OAC5A-L
Standard, Normally Closed, Random Turn-on 70-OAC5A5
Standard, Normally Open, Random Turn-on 70-OAC5A-11 70-OAC24A-11
Standard, Normally Open, ZVT 70-OAC5 70-OAC5A 70-OAC15 70-OAC15A 70-OAC24 70-OAC24A
Standard, Normally Open, ZVT, Inductive Load 70-OAC5-L 70-OAC5A-L
Specifications Units
Nominal Line Voltage Vac 120 240 120 240 120 240
Load Voltage Range Vac 24-140 24-280 24-140 24-280 24-140 24-280
Minimum Peak Blocking Voltage Volts 400 600 400 600 400 600
Maximum Off-state Leakage @ 60Hz mA, rms 2 4 2 4 2 4
Nominal Logic Voltage (Vcc) Vdc 5 5 15 15 24 24
Logic Voltage Range Vdc 2.5-10 2.5-10 10-18 10-18 15-30 15-30
Max. Logic Supply Current @ Nominal Vcc mA 16 16 9 9 9 9
Nominal Input Resistance (Rx) W 240 240 1800 1800 2700 2700
Minimum Drop Out Voltage Vdc 1 1 1 1 1 1
Maximum Reverse Logic Voltage Vdc -5 -5 -5 -5 -5 -5
Type/Function Grayhill Part Number
Standard and Miniature Modules
SPECIFICATIONS: By Part Number
G5 Modules
Grayhill Part Number
70G-OAC5 70G-OAC5A 70G-OAC15 70G-OAC24 70G-OAC24A
70G-OAC5-L 70G-OAC5A-L 70G-OAC15-L 70G-OAC15A-L
Nominal Line Voltage Vac 120 240 120 240 120 240
Load Voltage Range Vac 24-140 24-280 24-140 24-280 24-140 24-280
Minimum Peak Blocking Voltage Volts 400 600 400 600 400 600
Maximum Off-state Leakage @ 60Hz mA, rms 2 4 2 4 2 4
Nominal Logic Voltage (Vcc) Vdc 5 5 15 15 24 24
Logic Voltage Range Vdc 4-6 4-6 8-20 8-20 18-32 18-32
Max. Logic Supply Current @ Nominal Vcc mA 20 20 12 12 8 8
Nominal Input Resistance (Rx) W 100 100 1000 1000 2700 2700
Minimum Drop Out Voltage Vdc 1 1 1 1 1 1
Maximum Reverse Logic Voltage Vdc -5 -5 -5 -5 -5 -5
OpenLine ® Modules
Type/Function Grayhill Part Number
Dual, Fusible, Normally Open, ZVT 70L-OAC 70L-OACA
Dual, Fusible, Normally Open, ZVT, Inductive Load 70L-OAC-L 70L-OACA-L
Specifications Units
Nominal Line Voltage Vac 120 240
Load Voltage Range Vac 24-140 24-280
Minimum Peak Blocking Voltage Volts 600 600
Maximum Off-State Leakage @ 60 Hz mA, rms 2 4
Nominal Logic Voltage Vdc 5 5
Logic Voltage Range Vdc 4.5-28 4.5-28
Max. Logic Supply Current @ Nominal Vcc mA 7/CH 7/CH
Module ID Resistance to Logic Ground W 2.15K 2.15K
Minimum Drop Out Voltage Vdc 1 1
Available from your local Grayhill Distributor. For
prices and discounts, contact a local Sales Office,
an authorized local Distributor or Grayhill.
Type/Function
G5 Fusible, Normally Open, ZVT
G5 Fusible, Normally Open, ZVT, Inductive Load
Specifications Units
I/O
7
