Thru-Hole DIP Switches

DIP Switches

SerieS 90B and 90GB

Machine insertable MidiP

diMenSiOnS

in inches (and millimeters)

OrderinG infOrMatiOn: tube Packaging

(each tube is 19.5 inches long)

featureS
• Tested for TO-116 Equipment
• Up to 10 Positions
• High Pressure, Reliable Contacts
• Molded (Sealed) Base and
Optional Top Seal
• RoHS Compliant

As viewed from the top of the switch in the
positions shown in the drawing.

CiRCUiTRy

additiOnal infOrMatiOn

Please visit our website for accessories.

Available from your local Grayhill Distributor.
For prices and discounts, contact a local
Sales Office, an authorized local Distributor or
Grayhill.

*The "S"in the part number denotes top tape seal versions. To order without top tape seal, leave
the "S" off the part number when ordering.

**Style "GB" contains 30µ gold plated terminals.

O

1 2 3 4 5 6 7 8

N

LENGTH ± .010 (0,25)

SEE CHART

.165 ± .005

(4,19 ± 0,13)

.195
(4,95)
MAX.

.020 ± .002 (0,51 ± 0,05) TYP.

.100 ± .005 (2,54 ± 0,13) TYP.

.085 ± .005 (2,16 ± 0,13) TYP.

.135 ± .010
(3,43 ± 0,25)
TYP.

.375

± .010

(9,53

± 0,25)

.012 ± .001
(0,30 ± 0,03)
TYP.

C

L

.290

(7,37)

MAX.

DESIGNED FOR

.100 X .300 (2,54 X 7,62)

ON CENTER HOLES

Switch is packaged as shown
here with all positions on.

OPEN CLOSED

Series

90HBW

90B

90GB

76

78

CONTACT SySTEM

No. of

Positions

length

inches

length

Metric

number

Per tube

Part number

2
3
4
5
6
7
8
9

10

.270"
.370"
.470"
.570"
.670"
.770"
.870"
.970"

1.070"

6,9 mm
9,4 mm

11,9 mm
14,5 mm
17,0 mm
19,6 mm
22,1 mm
24,6 mm
27,2 mm

60
47
37
31
26
23
20
18
16

90B02St
90B03ST
90B04St
90B05St
90B06ST
90B07St
90B08St
90B09St
90B10St

90GB02St
90GB03ST
90GB04St
90GB05St
90GB06ST
90GB07St
90GB08St
90GB09St
90GB10St
