Rocker and Paddle Switches
Slide DIP Switches
4
5
6
7
8
9
10 11 12
10
11
12
1
2
3
.050
(1.27)
.050
(1.27)
.150
(3.81)
.030
(0.76)
.100
(2.54)
.125
(3.18)
.500
(12.70)
.016
(0.40) .200
(5.08)
.190
(4.83)
Ш.073
(Ш1.85)
.565
(14.35)
EPOXY SEAL
.235
(5.97)
.200
(5.08)
.850
(21.59)
.190
(4.83)
.565
(14.35)
.150
(3.81)
OPTION
CODE DIM."A"
V2
V3
.460
(11,68)
.630
(16,00)
4 5 6
OPTION
CODE DIM."A"
V2
V3
.460
(11,68)
.630
(16,00)
1 2 3
DIM. "A"
.620
(15.75)
.020
(0.51)
.185
(4.70)
.030
(0.76)
EPOXY SEAL
.620
(15.75)
.125
(3.18)
.048
(1.22)
.125
(3.18)
.320
(8.13)
.185
(4.70)
.190
(4.83)
Ш.073
(1.85)
.370
(9.40)
Ш.073
(Ш1.85)
.125
(3.18)
.048
(1.22)
.320
(8.13)
.185
(4.70)
DIM. "A"
.620
(15.75)
.020
(0.51)
.185
(4.70)
.030
(0.76)
EPOXY SEAL
.620
(15.75)
.125
(3.18)
.162
(4.11)
.162
(4.11)
V2-V3 Vertical
Bracket
P.C. Mount
TerMiNATioN oPTioNS in inches (and millimeters)
SPeciFicATioNS
rATiNgS
contact rating: Q option - 5A with resistive
load @ 125 VAC or 28 VDC; 2A with resistive
load @ 250 VAC. R option - 0.4 VA max @ 20
Vmax (AC or DC)
electrical life: 40,000 make-and-break
cycles at full load
contact resistance: 10 milliohms max. initial
@ 2-4 VDC, 100 mA
insulation resistance: 1,000 megaohms
minimum
dielectic Strength: 1,000 V RMS @ sea
level
operating Temperature: -30°C to 85°C
Ul recognition: File number is E35289 MATeriAlS
case: Diallyl phthalate (DAP) (UL 94V-0)
rockers: Nylon (UL 94V-0)
Bushing: Stainless steel
Switch Support: Brass, tin-plated
Terminal/contacts: Brass with silver or gold
plate
Terminal Seal: Epoxy
orderiNg iNForMATioN
Available from your local grayhill component distributor.
For prices and discounts, contact a local Sales Office, an authorized local Distributor or Grayhill.
Series 47A: Miniature Rocker and Paddle Switches
4PdT
SPdT
dPdT
47ASP1J2M6RT
Series 47A Minature Rocker and Paddle Switches
Model: SPDT: SP1, SP2, SP3, SP4, SP5
DPDT: DP1, DP2, DP3, DP4, DP5
3PDT: 3P1, 3P2, 3P3, 3P4, 3P5
4PDT: 4P1, 4P2, 4P3, 4P4, 4P5
(See Model options.)
Actuator: R1, R2, R3, R4, R5, R6, R7
J1, J2, J3, J4, J5, J6, J7, J8 (See actuator options.)
RoHS Compliant
Contact: R = Brass alloy, gold plate over nickel plate
Q = Brass alloy, silver plated
Termination Options: M1, M2, M3, M6, M7, S6, V2, V3, W1, W2, W3, W4
(See Termination options.)
