Toggle Switches
SPeciFicATioNS
rATiNGS
contact rating: 0.4 VA max. @ 20V max.
(AC or DC)
Mechanical and electrical life: 30,000
make-and-break cycles at full load
contact resistance: 20 milliohms max. typ.
initial @ 2-4 VDC, 100 mA
insulation resistance: 1,000 megaohms
minimum
dielectic Strength: 1,500 V RMS @ sea
level
operating Temperature: -30°C to 85°C
MATeriAlS
case and Bushings: Glass-filled nylon 4/6,
flame retardant, heat stabilized (UL94V-0)
Actuator: Brass, chrome plated
contacts: Copper alloy, gold plate over nickel
plate
Terminals: Copper alloy, tin plate over nickel
plate
Terminal Seal: Epoxy
Tape and reel: 500 pcs/per reel
orderiNG iNForMATioN
Available from your local Grayhill component distributor.
For prices and discounts, contact a local Sales Office, an authorized local Distributor or Grayhill.
Series 34E: Sealed Surface Mount Toggle Switches
34EWMSP12M6RT
Series 34E Sealed Surface Mount Toggle Switches
Model: SPDT: WMSP1, WMSP2, WMSP3, WMSP4, WMSP5
(See Model options.)
Actuator: 1, 2, 3, 4 (See Actuator options.)
RoHS Compliant
Contact: R = Copper alloy, gold plate over nickel plate
Termination Options: M6, S6, M7 (See Termination options.)
