Joysticks
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Joysticks
ORDERING INFORMATION
For prices and custom configurations, contact a local sales office, an authorized distributor, or Grayhill's sales department.
Termination: C = Cable with Connector, P = Pin Header
67B - PA- 3C - S - 03C
Cable Length: 02 = 2.0 inches through 06 = 6.0 inches. 1 inch increments.
Leave blank if pinned. Example: 67B-PA-3C-S-P
Interface: C = I 2 C
Voltage: 3 = 3.3V
Joystick Shaft Limiting: 2 = 2-Way 20° Either Direction, 4 = 4-Way 20° in 4 Main Directions, A = All-Way 20° in Any Direction
Available Functions: J = Joystick Only, P = Joystick + Pushbutton, R = Joystick + Pushbuttons + Momentary Turn
Grayhill Series Number
Seal Option: S = With Sealing Boot, U = Without Sealing Boot
SPECIFICATIONS
Electrical Ratings
Supply Voltage (VVD): 3.3V ± .0.3V
High Level Input Voltage (VIH, Min):
0.7*VDD on SCL & SDA / 0.25*VDD+0.8 on Al
Low Level Input Voltage (VIL, Max):
0.3*VDD on SCL & SDA / 0.15*VDD on Al
Current Draw In Active Mode (IDDI): 3mA
Maximum @ VDD = 3.3V (J & P options only)
Current Draw In Sleep Mode (IDD2): 100uA
Maximum @ VDD = 3.3V (J & P options only)
Current Draw in Active Mode (IDD3): 4mA
Maximum @ VDD = 3.3V (R option has active
mode only)
Typical Operating Current: 4.0 mA at Vcc =
3.3V, T = 25°C
Maximum Operating Current: 7.0 mA over
3.0 < Vcc < 3.6V, -40°C < T < 85°C
Maximum Current Sunk By Any I/O Pin:
25mA
Leakage Current: ±5 nA Typ., ±125 nA Max
Low Level Output Voltage (VOL): 0.6V On
INTn & SDA @ IOL = 6mA, @ VDD = 3.3V
Measurement Frequency (Active Mode): 50
Samples/Sec
Response Time, Active Mode (T1): 20ms*
Response Time, Sleep Mode (T2): 80ms*
Output @ Maximum Joystick Deflection
(XMax, YMax): 50 Units
Output With Joystick Shaft Released
(Center Position): (0,0)
Nominal Startup Time (TP, W): 300ms
Physical & Mechanical Ratings
Vibration: Random, Meets MIL-STD-810G,
Method 514.6, Procedure I
Mechanical Shock: Meets per MIL-STD 202,
Method 213B Test Condition A
Transit Drop: Meets per MIL-ST-810G, Method
516.6, Procedure II
Terminal Strength: 10 lbs. Minimum, Tested
per MIL-STD-202, Method 211A
Push-Out Force: 60 lbs. Minimum
Pull-Out Force: 60 lbs. Minimum
Shaft Impact: 0.5 lb. Weight dropped 20x from
height of 1m
Shaft Side-Load: 45 lbs. Minimum
Mounting Torque: 3-5 in-lbs recommended, 8
in-lbs. Maximum
Joystick Actuation Force: 300g Peak ± 25%
Joystick Life: 1 million cycles minimum**
Pushbutton Life: 1 million actuations,
minimum
Rotational Life: 1 million turns, minimum in
each direction
Materials and Finishes
Housing: Thermoplastic
Backplate: Thermoplastic
Lockwashers: 304 Stainless Steel
Hex Nuts: 303 Stainless Steel
Shim Washers: 304 Stainless Steel
Shaft: 303 Stainless Steel
Cable Assembly: 26 AWG Stranded Copper
Conductors
Connector Body: Thermoplastic
Terminals: Phosphor Bronze
O-Rings: Fluorosilicone
Sealing Boot: Silicone Rubber Molded over
Thermoplastic Insert
Environmental Ratings
Seal: IP67, Meets IEC 60529 (sealed version
only)
Altitude: Tested per MIL-STD 202,
Method 105C
Thermal Shock: Meets MIL-STD 202,
Method 107G
Operating High Temperature: +85°C,
Tested per IEC 68-2-14, Test Na
Operating Low Temperature: -40°C,
Tested per IEC 68-2-14, Test Na
Storage High Temperature: +100°C,
Tested per IEC 68-2-2, Method Ba
Storage Low Temperature: -55°C,
Tested per IEC 68-2-1, Method Aa
Humidity: Meets MIL-STD 202,
Method 103B
Humidity, 85/85: 500 hours tested per MIL-
STD 202
Method 103B,
Solar Radiation: Tested per MIL-STD 810G,
Method 505.5, Procedure II
Chemical Resistance: Meets ISO 16750-5
Dielectric: Meets MIL-STD 202G,
Method 301
Insulation Resistance: Tested per MIL-STD
202G, Method 302
EMC Ratings
Radiated Immunity: Meets IEC 61000-4-3
Conducted Immunity: Meets IEC 61000-4-6
Radiated Emissions: Meets ANSI C63.4
Conducted Emissions: Meets EN 55022
Electrostatic Discharge: Meets IEC 61000-4-2
Power Frequency Magnetic Field: Meets IEC
61000-4-8
*Response time is the time from joystick movement to when new X,Y position data is available.
**One cycle is defined as a complete revolution of the shaft around the fixed perimeter, or one actuation in each of the 4 main directions, with return to center between each actuation.
Pictured with knob, p/n: 677702
