Pushbutton Switches
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Sealed Subminiature Pushbutton Switches
P.C. MOUNTING
.400
(10.16)
.016
(0.40)
.020
(0.50)
.400
(10.16)
Ш.043
(Ш1.09)
.201
(5,10)
.030
(0,76)
Ш.177
(Ш4,50)
.366
(9,30)
.161
(4,10)
.217
(5,50)
Ш.100
(Ш2,54)
EPOXY SEAL
.100
(2,54)
.100
(2,54)
SWITCH POSITION MODEL NO.
WSP9 OFF (ON)
()=MOMENTARY
SCHEMATIC
SPST
()=MOMENTARY
SWITCH POSITION MODEL NO.
WDP9
2-1
OFF
2-3
(ON)
TERM. COMM.
SCHEMATIC
SWITCH POSITION MODEL NO.
WSP8
2-1
ON
2-3
(ON)
TERM. COMM.
()=MOMENTARY
SCHEMATIC
3 N.O. N.C.1
2COMM.
SPDT DPST
Snap-in termination Options (Same P.C. mounting as V2, M6, M7 but with snap-in bracket)
SerieS 38G
diMenSiOnS
in inches (and millimeters)
Circuitry
V2
SPdt
S2 S6 S7
