Grayhill Pushbutton switches: Butt Contact 32 Series - Manual

Pushbutton Switches
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Butt Contact Pushbutton Switches
.100 (2,54) .200 (5,08)
TYP.
.120 (3,05)
.070 (1,78) .050 (1,27)
.100 – .004
(2,54 – 0,10) TYP.
BTWN. PINS OF
SAME SWITCH .100 – .004 (2,54 – 0,10) TYP.
BTWN. PINS OF STACKED
SWITCHES
.084 (2,13) DIA.
.110 (2,79)
.090 (2,29)
.400 (10,16)
.190 (4,83)
.100 – .004
(2,54 – 0,10)
.030 – .002
(0,76 – 0,05)
DIA. 4 PLS.
.272 (6,91)
.220 (5,59)
.100 (2,54)
.180
(4,57)
.100 – .004
(2,54 – 0,10)
.200 (5,08)
REF.
GRAYHILL GRAYHILL GRAYHILL GRAYHILL GRAYHILL
.050 (1,27)
XXXX
E.I.A.
DATE
CODE
SWitCH diMenSiOnS in inches (and millimeters)
Led diMenSiOnS in inches (and millimeters)
Unless otherwise stated, linear dimension tolerances are ± .010 (0,25); diameters are ± .005 (0,13)
Unless otherwise stated, linear dimension tolerances are ± .010 (0,25); diameters are ± .005 (0,13)
SerieS 32
SPSt and SPdt,
Stackable with Led
• Stackable, Provides Custom
Switch Arrangements
• .200" Centers When Stacked
• SPST–N.O., SPST–N.C. Circuitry
in the Same Package
• Process Compatible, Internally
Sealed Plunger
• Status/Reset or Press-to-Test
Functions with Companion LED
action total travel
Momentary .050 (1,27) Approx.
SWitCH CirCuitry
alternate Wiring
rating at Operations
28 Vdc at rated Part
resistive Load number
150 mA 100,000 32-01
.220 (5,59)
GRAYHILL
.200 (5,08) REF.
.100 (2,54)
.118 (3,0)
DIA.
.050 (1,27)
.100 (2,54)
.010
(0,25)
.180
(4,57)
.272
(6,91)
.100 (2,54)
.230 (5,84)
.110
(2,79)
.190
(4,83)
.020 (0,51)
SQ. 2 PLS.
C
CATHODE
SPSt n.C.
SPSt n.O.
N.O. N.O.
N.C. N.C.
SPdt
BreaK BeFOre
MaKe
N.O.
N.C.
C
CONNECT PINS
ON PC BOARD
Actuator
Actuator
E-9
