Rotary Switches
Keylock Rotary Switches
Style Description Angle of No. of Poles/ Positions Shorting or
throw Decks Deck Per Pole Non-Shrtg.
Series 71 Switches
30° 01 to 12 1 02 to 12* N or S
01 to 08 2 02 to 06 N or S
01 to 05 3 02 to 03 N or S
01 to 04 4 02 to 03 N or S
01 to 03 5 02 N or S
01 or 02 6 02 N or S
36° 01 to 12 1 02 to 10* N or S
01 to 08 2 02 to 05 N or S
choiceS
*For single pole switches with maximum positions, specify continuous rotation or fixed stop when ordering.
orDeriNg iNforMAtioN
71 L 30-03-1-12N-f
Series
Style Letter: L for standard; J for anti-static
Angle of throw: 30 or 36
Number of Decks: 01 thru 12 (per Choices chart)
Poles per Deck: 1 thru 6 (per Choices chart)
Positions per Pole: 02 thru 12 (per Choices chart)
type of contacts:
N = Non-shorting
S = Shorting
Stop Arrangement Suffix:
(needed only for 1-pole switches with maximum positions)
F = Fixed stop between last and first positions
*Leave blank for continuous rotation
Lock SPecificAtioNS
Mounting: By bushing, nut and lockwasher
Static Voltages: Anti-static style withstands
15,000 Vdc
keying: All locks have identical keys unless
specially ordered otherwise
StANDArD Switch PAgeS
For additional switch dimensions, ratings, circuitry,
and specifications, see Series 71 datasheet.
Available from your local
grayhill Distributor.
For prices and discounts,
contact a local Sales Office,
an authorized local Distributor or Grayhill.
key removal
30° Throw:
Position 1 and 180°
Special key removal: Every 90°
36° Throw:
All positions
Special key removal: Position 1 only
orientation of keylock Switch: Bushing flats
are on both sides of the mounting thread with
the key upright in the first position with cut side
down.
Lock MAteriALS & fiNiSheS
keys: Brass; 2 supplied
Lock Bezel: Stainless steel
Lock Barrel & Plug: Zinc treated with
chromate
Lock Adaptor/extension: Thermoplastic
L Standard, Solder Lugs
J Anti-static, Solder Lugs
