Grayhill Single Deck Rotary Switches 56 Series - Manual (Page 4)

Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
Rotary Switches
Single Deck Rotary Switches
Angle Number Number Of Shorting Or
Of Of Positions Non-Shorting
Throw Poles Per Pole Contacts
CHOICES AnD LIMITATIOnS: Series 56
30°
36°
Screwdriver
Slotted Shaft
Equivalent
Adjustable
Stops 1
Shaft/Panel
Seal
PC Mount
Terminals
Solder Lug
Terminals
Style
Designation
FEATURES
A X B
S X X BS
P
X BP
SP X X BSPD
X
X BD
SD X X X BSD
DP X X
BDP
SDP X X X BSDP
1 Adjustable stop versions allow selection of 2 positions to the maximum number of positions per pole.
ORDERING INFORMAtION
1 02 thru 12 n or S
2 02 thru 06 n or S
4 02 or 03 n or S
1 02 thru 10 n or S
2 02 thru 05 n or S
Series
Style: Letters from Choices Chart
Angle of Throw: 30 or 36°
56A36S–01–1–10N–F
Stop Arrangement: The suffix C or F must be added to a one
pole per deck switch with the maximum number of positions to
indicate continuous rotation (C) or fixed stops (F) between posi-
tion 1 and the last position.
Type of Contacts: n = non-shorting, S = Shorting
Positions Per Pole: 02 as a minimum to the maximum
allowable for the angle of throw and number of poles per the
Choices Chart. use the letters Aj in this location if adjustable
stop switch is to be ordered.
Poles per Deck: Limited by angle of throw. See chart
Number of Decks: 01 only
Shafts: S= stainless steel, Blank= zinc die cast
StANDARD OPtIONS
Available from your local Grayhill Distributor
For prices and discounts, contact a local Sales
Office, an authorized local Distributor, or Grayhill.
not available thru Distributors when Intermixing
of shorting and non-shorting contacts. Contact
Grayhill.
A = Standard, 1/8" Shaft
B = Screwdriver Slot Shaft
D = Adjustable Stop (Adj. Stop)
P = PC Mount Terminals
S = Shaft/Panel Seal (S/P Seal)
