For other fastener types, refer to Table 22. It provides the withdrawal resistance for a number of different fastener types
(smooth-, ring- and screw-shank nails; wood screws and vinyl siding nails). Together with the
in the
2006 and 2009 International Residential Codes,
the attachment schedules for any
combination of siding type, continuous wood structural panel sheathing, design wind speed and exposure can be
determined. See
for more information
including wind load tables and a sample calculation.
TABLE 22
FASTENER WITHDRAWAL LOADS FOR THE ATTACHMENT OF SIDING TO CONTINUOUS WOOD STRUCTURAL
PANEL WALL SHEATHING
(a)
Ring-Shank Nails
(b)(c)
Withdrawal Loads (lbf)
Wall Sheathing
Performance
Category
Nail Diameter (in.)
0.091
0.094
0.097
0.113
0.120
0.128
0.135
0.148
0.099
3/8
31
32
33
38
41
43
46
50
7/16
36
37
38
45
48
51
53
59
15/32 and 1/2
39
40
41
48
51
54
57
63
19/32 and 5/8
49
51
52
61
64
69
73
80
23/32 and 3/4
59
61
63
74
78
83
88
96
Wood Screws
(c)(d)
Withdrawal Loads (lbf)
Wall Sheathing
Performance
Category
Screw Gauge/Diameter (in.)
#6
#7
#8
#9
#10
#12
#14
0.138
0.151
0.164
0.177
0.19
0.216
0.242
3/8
48
52
57
61
66
75
84
7/16
56
61
66
72
77
87
98
15/32 and 1/2
60
65
71
77
82
93
105
19/32 and 5/8
76
83
90
97
104
118
133
23/32 and 3/4
92
100
109
117
126
143
161
Smooth-Shank and Screw-Shank Nails
(c)(e)
Withdrawal Loads (lbf)
Vinyl Siding Nails
(c)(e)(f)
Withdrawal Loads
Wall Sheathing
Performance
Category
Nail Diameter (in.)
Nail Diameter (in.)
0.092
0.099
0.113
0.120
0.128
0.131
0.135
0.148
0.122
0.125
3/8
8
8
9
10
11
11
11
12
10
10
7/16
9
10
11
12
13
13
13
14
12
12
15/32 and 1/2
10
10
12
13
13
14
14
16
13
13
19/32 and 5/8
12
13
15
16
17
17
18
20
16
17
23/32 and 3/4
15
16
18
19
21
21
22
24
20
20
(a) Withdrawal capacities are based on the duration of load factor of 1.6 for wind applications. Adjustments for wet service and temperature are
normally not required for attachment to the wood structural panel nailable sheathing.
(b) For ring-shank nails, the withdrawal capacities (W) are based on specific gravities (G) of 0.70 in accordance with
and
W = 1380 G
2.5
D C
D
t, where: W = Withdrawal capacity (lbf), G = Specific Gravity, D = Nail diameter (in.),
C
D
= Duration of load factor (1.6 for wind loads), and t = wood structural panel thickness (in.).
(c) Fasteners shall be long enough to fully penetrate wood structural panel sheathing by at least 1/4 inch.
(d) For wood screws, the withdrawal capacities (W) are based on specific gravities (G) of 0.45 in accordance with
and
W = 2850 G
2
D C
D
t, where: W = Withdrawal capacity (lbf), G = Specific Gravity, D = Nail diameter (in.),
C
D
= Duration of load factor (1.6 for wind loads), and t = wood structural panel thickness (in.).
(e) For smooth-shank, screw-shank, and vinyl siding nails, the withdrawal capacities (W) are based on specific gravities (G) of 0.40 in
accordance with
and
W = 1380 G
2.5
D C
D
t, where: W = Withdrawal capacity (lbf), G = Specific Gravity, D = Nail diameter (in.),
C
D
= Duration of load factor (1.6 for wind loads), and t = wood structural panel thickness (in.).
(f) Vinyl siding nails shall have a head of at least 3/8 inch in diameter.
