No other winch available anywhere offers you the same time-tested, rugged per-
formance as the Adams winch. Now the best cable pulling winch your money can
buy comes loaded with new performance features, and its more compact design
takes up less than 25 in. of space on either side of the drum centerline with no sacri-
fice in capacity. What’s more, we’ve simplified the installation to give the Adams the
lower installed cost compared to any other winch in its class.
Rated to a bare drum pulling capacity of 20,000 lbs. (89 kN)
Model WG Winch Specifications
● Hydraulic system flow 20 GPM (76 l/min.) maximum; Hydraulic system pres-
sure 1750 psi (12066 kPa) operating with 2000 psi (13790 kPa) maximum relief
valve setting.
● Winch line speed is based on 7/16 in. (11.1 mm) diameter wire rope.
● The line pull ratings shown are the winch only. Consult the wire rope manufac-
Control Valve
Position
Max. Rated Line Pull Winch Line Speed Shaft Speed
@ 20 GPM
Bare Drum Full Drum Bare Drum Full Drum
Lbs. Force (kN) Lbs. Force (kN) Ft./min.(m/
min.)
Ft./min.(m/
min.)
RPM
High 10000 (44.5) 4600 (20.5) 26.8 (8.2) 66 (20.1) 14
Low 20000 (89) 9200 (41) 14.4 (4.4) 35 (10.7) 7.5
Maximum Rated Line Pull & Line
General Machine Products Co., Inc.
3111 Old Lincoln Highway
Trevose, PA 19053 USA
TEL: 215-357-5500
FAX: 215-357-6216
E-MAIL: [email protected]
WEB: http://www.GMPtools.com
Standard Features
• Integrated 2 speed hydraulic motor
• Pneumatically actuated clutch
• Caliper type drag brake • Level-wind mechanism for 7/16 in. wire
rope which distributes the wire rope onto
the drum in tight, even lays
• Adjustable full load brake with automatic
engagement when power is reversed • 2 7/16 in. (Bell Standard) shaft extension
rated at 1000 lb
