General Machine Products Co., Inc.
3111 Old Lincoln Highway
Trevose, PA 19053 USA
TEL: 215-357-5500
FAX: 215-357-6216
E-MAIL: [email protected]
WEB: http://www.GMPtools.com
GMP reserves the right, without notice, to make changes in
equipment design or components as progress in engineering or
manufacturing methods may warrant.
All contents ©2007 GMP
5/02/2007 AK
Weight: 130 lbs. (59kg)
Max. Winch Line Pull, underground: 25,000 lbs. (111,205 N)
Max. Winch Line Pull, overhead: 14,000 lbs. (62,205 N)
Max. Wire Rope Diameter : 9/16" (14 mm)
Sheave: Hardened Steel
Finish: Zinc chromate primer
Fasteners: Certified in compliance with SAE J429
Mounting Sockets: Two corrosion-resistant zinc alloy sockets
Mounting Location: Tail shelf
Swivel: 360 degrees
Rotation: 58 anti-friction hardened steel balls
Rollers: All rollers are removable for passage of wire rope eye
Model UV-25
Specifications
