General Machine Products 70202 Universal Swivel Sheave 25000 lb User Manual
Page 7
7
Parts can be ordered from your local dealer or from the factory.
Item # Item
Qty. P/N
Item # Item
Qty. P/N
1
Base Weldment
1
15614
15
Plain Washer
2
16749
2
Outer Sleeve
1
15835
16
Cotter Pin
2
16811
3
Inner Sleeve
1
15815 17
Lower Weldment
1
30211
4
Spacer Plate
1
24128
18
Pin
1
24610
5
Lube Fitting
1
16977
19
Upper Roller Assy.
1
15612
6 Set
Screw
2
17578
20 Pin
2
24609
7
O-Ring
2
16817
21
Lower Roller Assy.
2
15613
8
Hardened Stl. Ball
58
16678
22
Hair Pin Cotter
3
17640
9
Hex Hd. Cap Scr.
12
16635
23
Hex Hd- Cap Scr.
1 1/4"-7x4Gr8
2 17746
10
Upper Weldment
1
30210
24
Socket, Bolt Block
2
15836
11
Soc. Hd. Cap Scr.
5
16812
25
Hex Hd. Cap Scr.
7/8-9x2 Gr5
2 17729
12
Sheave w/Bearing,
Sleeve & Fitting
1
26102
26
Hex Nut 7/8-9
2
17730
13
Sheave Shaft
1
15827
27
Soc. Hd. Cap Scr.
1
30022
14
Spring, right hand
1
24600
28
Soc. Hd. Cap Scr.
2
25337
14
Spring, left hand
1
24601
29
Washer
3
30021
