2
Table of
Contents
General
Precautions
!
The Model UV-25 Universal Swivel Sheave is designed
to swivel 360° and accept wire rope up to 9/16, in. (14
mm) diameter. The maximum-rated winch line pull for
underground applications is 25,000 pounds-force
(111,205 N-force); and for over head applications 14,000
pounds-force (62,000 N-force). The unit weighs 130 lbs.
(59kg).
GMP has designed and manufactured the Model
UV-25 sheave consistent with sound engineering and
manufacturing procedures. However, because of the na-
ture of the product's use, extreme caution should be ex-
ercised during installation and operation.
Use only the recommended mounting sockets and bolts
described on page 4 of this manual. Check each mount-
ing bolt for tightness periodically depending on the
amount of use.
Make certain that the body structure to which the
sheave is to be mounted is sufficiently strong to with-
stand the 25,000 pounds maximum allowable load to the
sheave.
General 2
Precautions 2
Installation 4
Lubrication 5
Ball Bearing Chamber 5
Sheave 5
Drawings 6
Parts 7
Specifications 7
