Gamber-Johnson 7160-0377-xx - Manual (Page 5)

.31
13.66 11.74
12.49
.91
2.44
8.20
4.20
.62
7.86
1.04
9.60
1.25
1.25
3.00
10.00
10.47
Dock and Power Supply Dimensions
.21
O .200 6X mounting holes
J6 - Female connector
(Out-put power to dock)
J5 - Male connector
(In-put power from vehicle)
.88
5.46
2.33
7.18 1.43
3.92
7160-0377
Recon CF31 Military Docking
Stattion Weight = 11 lbs
18-32 Vdc Power Supply
Weight = 1.50 lbs
.69
1/4-20unc stainless steel ground stud
(torque nut to 65-85 in/lbs)
1.25
Note: mounting hardware
supplied by others
