TEILE DIAGRAMM
1. Rotpunkt Suchfernrohr
2. Okular im Format 1,25"
(2 im Lieferumfang enthalten)
3. Zahngetriebe Fokussier-Mechanismus
4. Zusatzgeräte Ablageplattenstrebe
5. Schnellfreigabe Stativbein-Hebel
6. Schnelleinstell-Ablageplatte
7. Fernsteuerung für Mobilteil
8. Teleskop Hauptrohr
9. Schnelleinstell Aluminium Stativ
Teleskop-Teile-Diagramm
1.
3.
4.
5.
6.
7.
8.
9.
2.
78-8831 / 78-8846
1.
3.
7.
8.
2.
9.
6.
4.
5.
78-8840, 78-8850,
78-8890
