Parts list quick assembly diagram – Bushnell NORTH STAR GOTO 78-8840 User Manual
Page 7
7
2.
• Adjustable Aluminum Tripod Assembly
(Pre-assembled to Northstar Computerized Star Locator Base)
• Quick Release Accessory Tray
• Northstar Telescope with finger attachment nuts
• Red Dot Finderscope
• 2 Eyepieces
• Barlow Lens (Reflectors Only)
• 90˚ Erecting Prism (Maksutov Only)
PARTS LIST
QUICk ASSEMbLY DIAGRAM
1.
2.
78-8831 / 78-8846 / 78-8840
78-8850 / 78-8890
78-8831 / 78-8846
78-8840, 78-8850, 78-8890
A
B
C
