Bushnell DEEP SPACE 78-9518 - Manual

D
EEP
S
PACE
S
ERIES
675 x 4.5” Reflector Telescope
Model 78-9518
See pg. 2 (fig. 1)
fig. 1
1
2
3
4
5
6
7
8
9 10
11
12
13
14
15
16
17
1. Finderscope
2. Finderscope Mount
3. Rack & Pinion Focusing
Mechanism
4. Eyepiece
5. Fine Adjustment Cables (2)
6. Counterweight
7. Counterweight Shaft
8. Tripod Leg Middle Section
9. Accessory Tray Brace
10. Accessory Tray
11. Tripod Leg Lock Screws
12. Tripod Leg
13. Horizontal Axis Lock
14. Primary Mirror (Internal)
15. Telescope Main Tube
16. Finderscope Focus Adjustme
17. Finderscope Adjustment
Screws (3)
18. Declination Lock Knob
19. Declination Scale
20. Equatorial Mount
21. Right Ascension Lock Knob
22. Latitude Lock Knob
23. Latitude Scale
24. Right Ascension Scale
25. Cradles
