7
2.4GHz 5GHz
Standards 802.11b/g 802.11a
Certifications FCC / CE
Radio Specifications
Operating Frequency 2400 to 2497MHz 4900 to 6000MHz
Available Transmit Power
(software selectable) 802.11b 100 to 250mW
802.11g 50 to 100mW
10 to 250mW
Receive Sensitivity
-73 @ 54Mbps
-84 @ 11Mbps -74dBm @ 54 Mbps
-94dBm @ 6 Mbps
Security 64/128bit WEP, WPA, WPA2
Remote Configuration By IP Address; thru Wireless or Ethernet
Antenna Specifications
Antenna Gain 14 dBi 19 dBi
Antenna Beamwidth (H /V) 35/25 deg 21/10 deg
Antenna Front to Back >20dB >23dB
Polarization Vertical Vertical
POE Specification
Power Over Ethernet
INPUT: 100 – 240VAC @ 50 – 60Hz
OUTPUT: 18VDC @ 0.8A
Mechanical Specifications
Color White
Dimensions (L x W x H) 12.4” x 7.3” x 2.5” (314 x 187x 65mm)
System Weight 7 lb (3 kg)
Ethernet Connector RJ45
Mount Pole (up to 2” dia) or Wall
Environmental Specifications
Operating Temperature -31 to 140 Deg F (-35 to +60 Deg C)
Humidity 0 to 100% RH
Wind Loading
(125MPH survivability)
100MPH / 23lbs; 125MPH / 35lbs
Technical Specifications
Note: Subject to Change Without Notice
2.4GHz 5GHz
