Unison Mosaic RemoteManager User Manual
User Interface
The software has been designed to present a consistent graphical user interface and so it is worth familiarising
yourself with the layout of the main window before proceeding further:
Main toolbar
The buttons on the left of the main toolbar provide overall control of your RemoteManager project. Create new
projects, open existing projects and save your work using the
file management buttons. Use the Undo/Redo but-
tons to step backwards and forwards through operations that affect your project. Installations can be added,
edited or removed by using the installation buttons.
Installations Browser
Any installations that have been added to your RemoteManager project are listed here. Project templates occupy
the highest level, installations occupy the second tier and individual controllers occupy the third tier. The type of
controller is displayed, along with IP address, HTTP Port, FTP Port, Online Status, Next Upload, Upload State
and Upload Comments.
Log Viewer
The log viewer at the base of the screen displays actions by the time and date they were completed. These con-
firm whether an upload to a controller has been successful or unsuccessful, whether a controller has gone offline
or become connected, and whether media or media slots have been successfully transferred to the controller.
