Page 15
Page 15
L1
BLK
TANK HEATER
WHI
LOWER WARMER
1150W
BLK
SCHEMATIC WIRING DIAGRAM VPR
GREEN
N
WHI
WHI
BLK
10050.0000D 1/97 © 1988 BUNN-O-MATIC CORPORATION
UPPER WARMER
WHI
WHI
BLK
120 VOLTS A C
2 WIRE
SINGLE PHASE
60 HZ
WHI/RED
WHI/RED
VIO
VIO
100W
100W
LIMIT
THERMOSTAT
BLU/BLK
SW. & THERMOSTAT
ON/OFF
SWITCH
ON/OFF
SWITCH
IND
IND
10053 073001
L1
BLK
TANK HEATER
WHI
LOWER WARMER
"KEEP WARM" HEATER
WHI
BLK
SCHEMATIC WIRING DIAGRAM VPR
GREEN
N
WHI
WHI
BLK
33769.0000A 02/01 © 2001 BUNN-O-MATIC CORPORATION
UPPER WARMER
WHI
BLK
120 VOLTS A C
2 WIRE
SINGLE PHASE
60 HZ
WHI/RED
VIO
LIMIT
THERMOSTAT
BLU/BLK
SW. & THERMOSTAT
ON/OFF
SWITCH
ON/OFF
SWITCH
WHI
WHI
(Prior to Serial # VPR0270000)
(Serial # VPR0270000 & up)
