4.8. Status Indications
The following table lists the Flute amplifier status indications.
Function
Latch
Option
AOK
SO1
SO2
SO3
1
Amplifier OK
(AOK)
N/A
Low
Open collector
Open collector
Open collector
2
External disable
No
Low
Low
Open collector
Low
3
Current limit
No
Low
Open collector
Open collector
Low
4
Short
Yes
Open collector
Low
Open collector
Low
5
Over temperature Yes
Open collector
Open collector
Low
Low
6
Internal supplies
protection
No
Open collector
Low
Low
Open collector
7
Under voltage
No
Open collector
Low
Open collector
Open collector
8
Over voltage
No
Open collector
Open collector
Low
Open collector
9
Shunt*
No
Low
Open collector
Low
Open collector
10 Power Up Reset
No
Open collector
Open collector
Open collector
Open collector
* This indication can be used as a digital input for activating an external shunt regulator.
Table 9: Flute Status Indications
Notes:
•
Without latch mode:
The status indications are reset when the fault disappears.
•
With latch mode:
The Short, Over Temperature and Commutation Failure status indications are reset when
the enable signal is temporarily removed from the enable input.
•
Multiple faults:
Only the reading of the first fault is reliable. Additional faults add on to the status outputs
and the indication is therefore meaningless.
